Flame Sensor

Overview

Sensitive to flame spectrum
Features wide range voltage comparator LM393
Adjustable sensitivity
Signal output indicator

Specifications

Spectrum range: 760nm ~ 1100nm
Detection angle: 0 - 60 degree
Power: 3.3V ~ 5.3V
Operating temperature: -25℃ ~ 85℃
Dimension: 27.3mm * 15.4mm
Mounting holes size: 2.0mm

Applications

Fire detection
Fire fighting robot
Fire alarm

How to Use

In the case of working with a MCU:

VCC ↔ 3.3V ~ 5.3V
GND ↔ power supply ground
AOUT ↔ MCU.IO (analog output)
DOUT ↔ MCU.IO (digital output)

Note: the Flame Sensor is used for detecting fire without any fire-protection for itself, please keep distance from the fire to avoid damage.

Photos

Downloads

Development resources: demo codes, schematic, datasheets, etc.
Wiki: www.waveshare.com/wiki/Flame_Sensor
